Key Features
6× Extended Magnification Provides powerful 6× magnification to significantly extend the effective range of red dot optics for precision shooting.Flip-to-Side Quick Detach Mount Ambidextrous QD mount allows rapid transition between magnified and unmagnified shooting configurations.Absolute & Lower 1/3 Co-Witness Compatibility Included spacer allows alignment with both absolute and lower 1/3 height red dot optics.Extended Eye Relief 65 mm eye relief provides comfortable shooting positions while maintaining a full and consistent sight picture.Adjustable Diopter System ±3 diopter adjustment allows users to fine tune focus for their eyesight and maintain a sharp image.
Optical Specs
| Magnification | 6x |
|---|---|
| Exit Pupil | 4.6mm |
| Eye Relief | 65mm |
| Field of View | 3.7° |
| Diopter | ±3D |
| Transmittance | .75 |
| Lens Material | Optical Glass |
Mechanical Specs
| Housing Material | 7075 T6 Aluminum |
|---|---|
| Surface Finish | Anodized |
| Housing Color | Black |
Physical Specs
| Dimension (in) Body | 4.33″ × 1.8″ × 2.5″ |
|---|---|
| Body (oz) Weight | 11.6 oz |
| Central Height Mount | 1.41 / 1.63 |
Environment Specs
| Storage Temperature | -40°C ~ 70°C |
|---|---|
| Working Temperature | -30°C ~ 60°C |
| Submersion | IP67 |
| Vibration | 1000G |
Functions
| Flip To Side Mount | Yes |
|---|---|
| Compatible with Absolute & Lower 1/3 Height Optics | Yes |
| QD Mount & Spacer Included | Yes |
Fitment
| Direct Mount | Picatinny Rail |
|---|
Package Contents
| ● | HM6X |
| ● | Lower 1/3 Spacer |
| ● | Lens Cloth |
| ● | Multi-Tool |
| ● | Manual |
| ● | Warranty Card |
